18.5 inch LCD Display with Outline Dimension 431*255*9.2mm 1920*1080 Resolution and 0-50C LVDS LCMA-RX0185GB10-C050

Place of Origin Shenzhen
Brand Name ROGIN
Model Number LCMA-RX0185GB10-C050
Document LCMA-RX0185GB10-C050.pdf
Minimum Order Quantity 5
Price Price is negotiable.
Packaging Details Cartons or wooden cases
Delivery Time 4-6weeks
Payment Terms T/T,L/C
Supply Ability Spot adequacy

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Panel Size 18.5" Resolution 1920*1080
Brightness 500 (Typ.) Aspect Ratio 16:9
Active Area 409.8*230.04mm (A.A) Outline Dimension 431*255*9.2mm
Highlight

LCMA-RX0185GB10-C050

,

1920*1080 LCD Display

,

18.5 inch LCD Display

Leave a Message
Product Description

18.5 inch High Brirghtness LCD Display

Product Feature ►


1. Brightness customization 700-5000cd/m2.
2.Outdoor sunlight readable.
3. Low power consumption.
4.High uniformity up to 85%.
5.Aluminium backlight structure with good heat dissipation.
6.Wide temperature range up to -30°C-80°C.
7.High shock resistance and high stability.

Product Application


1.Bus Stop Station
2.Intelligent Charging Pile.
3.Outdoor Electronic News Reading Board.
4.Intelligent Express Cabinet.
5.Vending Machine.
6.Commercial Advertising.
7.Attractions Information Inquiry Machine.
8.Community Information Board.

18.5 inch LCD Display with Outline Dimension 431*255*9.2mm 1920*1080 Resolution and 0-50C LVDS LCMA-RX0185GB10-C050 0 18.5 inch LCD Display with Outline Dimension 431*255*9.2mm 1920*1080 Resolution and 0-50C LVDS LCMA-RX0185GB10-C050 1 18.5 inch LCD Display with Outline Dimension 431*255*9.2mm 1920*1080 Resolution and 0-50C LVDS LCMA-RX0185GB10-C050 2 18.5 inch LCD Display with Outline Dimension 431*255*9.2mm 1920*1080 Resolution and 0-50C LVDS LCMA-RX0185GB10-C050 3

Data sheet


LCMA-RX0185GB10-C050

  Brand   Rogin
  Series   High Brightness LCD Display
  Panel Size(inch)
  18.5
  Model
  LCMA-RX0185GB10-C050
  Brightness
  500
  Resolution
  1920*1080
  Active Area
  409.8*230.04
  Overall Size
  431*255*9.2
  Viewing Angle
  89/89/89/89
  Interface Definition
  LVDS (2 ch, 8-bit)
  Backlight Type   WLED
  Contrast Ratio
  1000:1
  Aspect Ratio
  16:9
  Touch Panel   Without
  Operating Temperature
  0-50℃
