15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150

  • 15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150
  • 15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150
Place of Origin Shenzhen
Brand Name ROGIN
Model Number LCMA-RX0150GR01-C150
Minimum Order Quantity 5
Price Price is negotiable.
Packaging Details Cartons or wooden cases
Delivery Time 6-8 weeks
Payment Terms T/T,L/C
Supply Ability Spot adequacy

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name High Brightness LCD Display Panel Size 15.0"
Resolution 1024*768 Brightness 1000 (Typ.)
Aspect Ratio 4:3 Active Area 304.128*228.096mm
Outline Dimension 326.5*253.5*9.7mm
Leave a Message
Product Description

15.0 inch High Brirghtness LCD Solution 1024*768 1500nits

Product Features ►

1. Brightness customization 700-5000cd/m2.
2. Outdoor sunlight readable.
3. Low power consumption.
4. High uniformity up to 85% .
5. Aluminium backlight structure with good heat dissipation.
6. Wide temperature range up to -30°C-80°C.
7. High shock resistance and high stability.

Product Application ►

1.Bus Station Signage System.
2.Smart Charging Station.
3.Outdoor Electronic News Display.
4.Smart Parcel Delivery Locker.
5.Vending Machine.
6.Commercial Digital Signage.
7.Tourist Attraction Information Kiosk.
8.Community Bulletin Board.
15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150 0 15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150 1 15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150 2 15.0 Inch High Brightness Solution 1024*768 LVDS With 1500nits LCMA-RX0150GR01-C150 3

Specifications ►

LCMA-RX0150GB03-C100

  Brand   Rogin
  Series   High Brightness LCD Display
  Panel Size(inch)
   15.0
  Model
   LCMA-RX0150GR01-C150
  Brightness
   1500nits
  Resolution
   1024*768
  Active Area(mm)
   304.128*228.096mm
  Overall Size(mm)
   326.5*253.5*9.7mm
  Viewing Angle
   89/89/89/89
  Interface Definition
   LVDS (1 ch, 8-bit)
  Backlight Type   WLED
  Contrast Ratio
   1000:1
  Aspect Ratio

  4:3
  Touch Panel   Without
  Operating Temperature
   -20-70℃
