13.3 Inch TFT LCD Solution 800nits Brightness Solution Wide Temperature Display
Product Details
| Name | 13.3 Inch TFT LCD Display | Panel Size | 13.3" |
|---|---|---|---|
| Resolution | 1920*1080 | Brightness | 800 (Typ.) |
| Aspect Ratio | 16:9 | Active Area | 293.76*165.24mm |
| Outline Dimension | 307.6*183.05*6.7mm | Interface | EDP (2 Lanes) |
| Highlight | 13.3 inch TFT LCD display,800nits brightness LCD solution,wide temperature LCD display |
||
Product Description
13.3 Inch TFT LCD Solution 800nits Brightness Solution Wide Temperature Display
Product Advantages
- Brightness customization 700-5000cd/m²
- Outdoor sunlight readable
- Low power consumption
- High uniformity up to 85%
- Long lifetime, 50K hours (Typ), up to 80K hours
- Aluminium backlight structure with good heat dissipation
- Wide temperature range up to -30°C-80°C
- High shock resistance and high stability
Product Applications
- Bus Station Signage Board
- Intelligent Charging Pile
- Outdoor Electronic News Reading Board
- Intelligent Express Cabinet
- Vending Machine
- Commercial Advertising Machine
- Attractions Information Inquiry Machine
- Community Information Board
Specifications
| Model | LCMA-RX0133GB02-C080 |
| Brand | Rogin |
| Series | High Brightness LCD Display |
| Panel Size (inch) | 13.3 |
| Brightness | 800nits |
| Resolution | 1920*1080 |
| Active Area | 293.76*165.24mm |
| Overall Size | 307.6*183.05*6.7mm |
| Viewing Angle | 89/89/89/89 |
| Interface Definition | eDP (2 Lanes) |
| Backlight Type | WLED |
| Contrast Ratio | 1000:1 |
| Aspect Ratio | 16:9 |
| Touch Panel | Without |
| Operating Temperature | -20~70℃ |
