18.5 Inch Wide Temperature LCD Support Android System Smart Home Area
Product Details
| Name | 18.5 Inch TFT LCD Display | Panel Size | 18.5" |
|---|---|---|---|
| Resolution | 1920*1080 | Brightness | 1000 (Typ.) |
| Aspect Ratio | 16:9 | Active Area | 408.96*230.04mm |
| Outline Dimension | 430.4*254.6*12.5mm | Interface | LVDS (2 Ch, 8-bit) |
| Highlight | 18.5 inch LCD display,wide temperature LCD screen,Android-compatible smart home display |
||
Product Description
18.5 Inch Wide Temperature LCD Support Android System Smart Home Area
Product Overview
High-performance 18.5-inch LCD display with Android system support, designed for smart home applications and demanding outdoor environments.
Model: LCMA-RX0185GA07-C100
Key Advantages
- Brightness customization 700-5000 cd/m²
- Outdoor sunlight readable display
- Low power consumption design
- High uniformity up to 85%
- Long lifetime: 50K hours (Typical), up to 80K hours
- Aluminium backlight structure with excellent heat dissipation
- Wide temperature range: -30°C to 80°C
- High shock resistance and operational stability
Application Areas
- Bus Station Signage Boards
- Intelligent Charging Piles
- Outdoor Electronic News Reading Boards
- Intelligent Express Cabinets
- Vending HMI Machines
- Commercial Advertising Machines
- Attractions Information Inquiry Machines
- Community Information Boards
Product Images
Technical Specifications
| Brand | Rogin |
|---|---|
| Series | High Brightness LCD Display |
| Panel Size | 18.5 inch |
| Model | LCMA-RX0185GA07-C100 |
| Brightness | 1000 nits |
| Resolution | 1920×1080 (Full HD) |
| Active Area | 408.96×230.04 mm |
| Overall Size | 430.4×254.6×12.5 mm |
| Viewing Angle | 89/89/89/89 |
| Interface Definition | LVDS (2 ch, 8-bit) |
| Backlight Type | WLED |
| Contrast Ratio | 1000:1 |
| Aspect Ratio | 16:9 |
| Touch Panel | Without |
| Operating Temperature | -30°C to 80°C |
