23.8 Inch High Brightness TFT Display Sunlight Readable LCD for Outdoor Control Panels
Product Details
| Name | 23.8 Inch TFT LCD Display | Panel Size | 23.8" |
|---|---|---|---|
| Resolution | 1920*1080 | Brightness | 3500 (Typ.) |
| Aspect Ratio | 16:9 | Active Area | 527.04*296.46mm |
| Outline Dimension | 554.04*323.53*41mm | Interface | LVDS (2 Ch, 8-bit) |
| Power | 97.5W | Application | Smart Home/Industrial Equipment/Medical Devices/Outdoor |
| Highlight | 23.8 inch sunlight readable LCD display,high brightness TFT display for outdoor panels,sunlight readable LCD for control panels |
||
Product Description
23.8 Inch High Brightness TFT Display Sunlight Readable LCD for Outdoor Control Panels
Product Advantages
- Brightness customization 700-5000cd/m²
- Outdoor sunlight readable
- Low power consumption
- High uniformity up to 85%
- Long lifetime: 50K hours (Typical), up to 80K hours
- Aluminium backlight structure with excellent heat dissipation
- Wide temperature range: -30°C to 80°C
- High shock resistance and stability
Product Applications
- Bus Station Signage Board
- Intelligent Charging Pile
- Outdoor Electronic News Reading Board
- Intelligent Express Cabinet
- Vending HMI Machine
- Commercial Advertising Machine
- Attractions Information Inquiry Machine
- Community Information Board
Specifications
Model: LCMA-RX0238GA02-Z350
| Brand | Rogin |
|---|---|
| Series | High Brightness LCD Display |
| Panel Size (inch) | 23.8 |
| Model | LCMA-RX0238GA02-Z350 |
| Brightness | 3500 nits |
| Resolution | 1920 × 1080 |
| Active Area | 527.04 × 269.46 mm |
| Overall Size | 554.04 × 323.53 × 41 mm |
| Viewing Angle | 89/89/89/89 |
| Interface Definition | LVDS (2 ch, 8-bit) |
| Backlight Type | WLED |
| Contrast Ratio | 3000:1 |
| Aspect Ratio | 16:9 |
| Touch Panel | Without |
| Operating Temperature | 0°C to 50°C |
