5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel

5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel
5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel

Large Image :  5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel

Product Details:
Place of Origin: Shenzhen
Brand Name: ROGIN
Model Number: RX050A-0701-C
Payment & Shipping Terms:
Minimum Order Quantity: 5
Price: Price is negotiable.
Packaging Details: Cartons or wooden cases
Delivery Time: 6-8 weeks
Payment Terms: T/T, L/C
Supply Ability: Spot adequacy
Contact Now

5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel

Description
Panel Size: 5.0" Resolution: 800(RGB)*480
Brightness: 600 (Typ.) Active Area: 108(W) X64.8 (H) Mm
Outline Dimension: 120.7(W) X75.8(H) Xx4.98(D)mm Name: Small LCD Display
Highlight:

Medium And Small LCD Display

,

5.0 Inch Small LCD Display

,

RGB 500 Nits Display

5.0 inch Medium and Small LCD Display 800(RGB)×480 RGB 500nits (with touch panel)

Product Advantage ►

1. Thousand grade clean room, Cover 3000 m2 dust-free workshop.
2. Support small MOQ and LCD/FPC/BL/TP customization.
3. Customized convert board, RBG/LVDS/MIPI/EDP/ HDMI signal conversion.
4. Strict aging test and vibration test.

Product Application ►

1. Educational Learning Machine.
2. Car DVD.
3. Communication Equipments.
4. Handheld Devices.
5. Car Rearview Mirror and Data Recorder.
6. Medical Equipments.
7. Instrument.
8. Instrial Control Display.

5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 0 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 1 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 2 5.0 Inch Medium And Small LCD Display 800×480 RGB 500 Nits Display With Touch Panel 3

Specifications ►

RX050A-0701-C

 Brand  Rogin
 Series  Medium and Small Size LCD Display
 Panel Size  5.0inch
 Model  RX050A-0701-C
 Brightness  500 cd/m2
 Resolution  800(RGB)*480 dots
 Interface  RGB
 Display area(AA)  108(W) x64.8 (H) mm
 Overall size  120.7(W) x75.8(H) x4.98(D)mm
 Driver element  a-Si TFT active matrix
 Display colors  16.7M colors
 Pixel arrangement  RGB-stripe
 Pixel pitch  0.135(W) ×0.135(H) mm
 Viewing angle  6 O'CLOCK
 Drive IC  ILI6122 + ILI5960
 Display mode  Transmissive/ Normally White
 Operating temperature  -20~+70℃
 Storage temperature  -30~+80 ℃

Tag:

Small LCD Screen,

RGB LCD Display,

MCU LCD Display
