High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness

  • High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness
  • High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness
  • High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness
Place of Origin Shenzhen
Brand Name ROGIN
Model Number LCMA-RX0104GR02-C150
Minimum Order Quantity 5
Price Price is negotiable.
Packaging Details Cartons or wooden cases
Delivery Time 6-8 weeks
Payment Terms T/T, L/C
Supply Ability Spot adequacy

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Panel Size 10.4" Resolution 1024*768
Brightness 1500 (Typ.) Aspect Ratio 4:3
Active Area 210.43*157.824mm Outline Dimension 227*175.8*9.2mm
Highlight

LVDS High Brightness LCD Display

,

10.4 inch High Brightness LCD Display

,

1500nits High Brightness LCD Display
Leave a Message
Product Description

10.4 inch High Brirghtness LCD Display 1024*768 LVDS 1500nits

Product Advantage ►

1. Brightness customization 700-5000cd/m2.
2. Outdoor sunlight readable.
3. Low power consumption.
4. High uniformity up to 85% .
5. Long lifetime, 50K hours(Typ), up to 80K hours
6. Aluminium backlight structure with good heat dissipation.
7. Wide temperature range up to -30°C-80°C.
8. High shock resistance and high stability.

Product Application ►

1. Bus Station Signage Board.
2. Intelligent Charging Pile.
3. Outdoor Electronic News Reading Board.
4. Intelligent Express Cabinet.
5. Vending Machine.
6. Commercial Advertising Machine.
7. Attractions Information Inquiry Machine.
8. Community Information Board.
High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness 0 High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness 1 High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness 2 High Brightness 10.4 inch LCD Display 1024*768 LVDS 1500nits with 1500nits Brightness 3

Specifications ►

LCMA-RX0104GR02-C150

  Brand   Rogin
  Series   High Brightness LCD Display
  Panel Size(inch)
   10.4
  Model
   LCMA-RX0104GR02-C150
  Brightness
   1500
  Power Consumption (W)
   10
  Resolution
   1024*768
  Active Area
   210.43*157.824
  Overall Size
   227*175.8*9.2
  Viewing Angle
   85/85/85/85
  Interface Definition
   LVDS (1 ch, 6/8-bit)
  Backlight Type   WLED
  Contrast Ratio
   900:1
  Aspect Ratio
   4:3
  Touch Panel   Without
  Operating Temperature
   -30~80℃
